CROSS SECTIONAL LINE DRAWING
Corrugate
- A TRUE KIWI ICON
- Corrugate profile is cost effective and versatile, able to handle a wide range of roofing and wall cladding applications. Corrugate profile can also be bullnose curved. Corrugate is available in Zincalume®, Galvsteel®, COLORSTEEL® Maxam™.
- Cover
- 760 mm
- Sheet Width
- 851 mm
- Minimum Pitch
- 8°
- Curving
- Bullnose, Drape and Spring Curving options available
- Application
- Residential, Commercial, Rural, Industrial roofing and cladding
- Orientation
- Roofing and both vertically and horizontally laid cladding
- Availability
- Auckland, Whangarei, Hamilton, Palmerston North, New Plymouth, Hastings, Wellington, Christchurch, Cromwell. Available from all Metalcraft Roofing branches.
Downloads
Download AllInstallation details available for download in PDF, DWG, DXF & RVT files
Product Flyer
Environmental Choice Certificates
BPIS Building Product Information Sheet
Loadspan and Fixing Tables - Steel
Residential Roof Details
Residential Vertical Wall Cladding Details
Residential Vertical Direct Fixed
Residential Horizontal Wall Cladding Details
Commercial Roof Details
Commercial Vertical Wall Cladding
Commercial Horizontal Wall Cladding Details
COLORSTEEL® Colour Brochure
COLORSTEEL® Environmental Categories
COLORSTEEL® Fire Testing of Coated Steel Products
COLORSTEEL® Maintenance Recommendations
COLORSTEEL® Maxam™ Product Information Sheet
NZMRM Code of Practice Version September 2023
NZMRM Installation Guide
Masterspec Specification Link
Metalcraft Profile Spec Details
MINIMUM PITCHES
The minimum pitch is determined by the ability of the roof cladding to discharge maximum rainfall without water penetration through the side laps or flashings. The minimum pitch for Corrugate is: 8° after deflection for sheet lengths of 30m. 9° after deflection for sheet lengths exceeding 30m but less than 50m.
The above minimum requirement has been calculated assuming peak rainfall to be less or equal to 100mm/hr.
What now?
THE COLORSTEEL® RANGE
All colours are available in COLORSTEEL® Maxam™. Please note colours below are indicative and we recommend you request a steel colour sample from your nearest Metalcraft Roofing branch. The homeowner should be aware that temperatures of dark colours are higher than those of lighter colours. Darker colours will thermally expand more. Thermal expansion of metal roofs is covered in the MRM Code of Practice. The MBIE document on roof cladding advises that noise from thermal expansion is normal and should be expected. Refer to MBIE -Guide to tolerances, materials and workmanship in new residential construction 2015.
