CROSS SECTIONAL LINE DRAWING

Metrib 750
- About
- Metrib750 is a 6 rib trapezoidal profile which is ideal for residential roof and wall cladding solutions. Metrib750 can also be used in commercial wall cladding
- Cover
- 750 mm
- Sheet Width
- 800 mm
- Minimum Pitch
- 8° (minimum pitch will increase depending on sheet lengths - please refer to information sheet.)
- Curving
- Bullnose, Drape and Spring Curving options available
- Application
- Residential, Commercial, Rural, Industrial roofing and cladding
- Orientation
- Roofing and both vertically and horizontally laid cladding
- Availabilty
- Manufactured in Hamilton. Available from all Metalcraft Roofing branches.
Downloads
Download AllInstallation details available for download in PDF, DWG, DXF & RVT files
Product Flyer
Product Technical Statement
Loadspan and Fixing Tables - Steel
Residential Roof Details
Residential Vertical Wall Cladding Details
Residential Horizontal Wall Cladding Details
Metalcraft Roofing Company Profile
Fire Testing of Coated Steel Products
Colorsteel Environmental Categories
Colorsteel Colour Brochure
Masterspec Specification Link

Metrib750 is a 6 rib trapezoidal profile which is ideal for residential roof and wall cladding solutions. Metrib750 can also be used in commercial wall cladding.
MINIMUM PITCHES
The minimum pitch is determined by the ability of the roof cladding to discharge maximum rainfall without water penetration through the side laps or flashings. The minimum pitch for Metrib 750 is: 8° after deflection for sheet lengths of 30m. 9° after deflection for sheet lengths exceeding 30m but less than 50m. The above minimum requirement has been calculated assuming peak rainfall to be less or equal to 100mm/hr.
What now?
THE COLORSTEEL® RANGE
All colours are available in COLORSTEEL® ENDURA® and COLORSTEEL® MAXX®. Please note colours below are indicative and we recommend you request a steel colour sample from your nearest Metalcraft Roofing branch. The homeowner should be aware that temperatures of dark colours are higher than those of lighter colours. Darker colours will thermally expand more. Thermal expansion of metal roofs is covered in the MRM Code of Practice. The MBIE document on roof cladding advises that noise from thermal expansion is normal and should be expected. Refer to MBIE -Guide to tolerances, materials and workmanship in new residential construction 2015.
Karaka
Gull Grey
Permanent Green
Mist Green
Lichen
FlaxPod®
Ironsand
Lignite
Desert Sand
Slate
Grey Friars
New Denim Blue
Thunder Grey
Sandstone Grey
Cloud
Titania
Scoria
Pioneer Red
Ebony
Windsor Grey
